As a rental series product, the convenience and variability of installation are one of the starting points of research and development. It can be assembled into most standard sizes, and can also be hoisted, curved installed, stacked and other methods.
High contrast corrugated light
Absorbing mask
Achieve ultra-high contrast
Ultra thin
Reduced shipping costs and installation labor costs.
Reduce the load bearing of the steel frame structure and enhance the durability.
Lighter | Thinner | Smarter
500X500
8KG
The ability to restore colors is more powerful, intelligently restore 68.7 billion colors, so as to ensure the realism of images
As a rental series product, the convenience and variability of installation are one of the starting points of research and development. It can be assembled into most standard sizes, and can also be hoisted, curved installed, stacked and other methods.
| Pixel Pitch | P1.95 | P2.315 | P2.604 |
| LED Type | SMD1515 | SMD1515 | SMD1515 |
| Density(dots/㎡) | 262144 | 186624 | 147456 |
| Module Resolution | 128X128 | 108X108 | 96X96 |
| Module Size(wXh) | 250X250 | 250X250 | 250X250 |
| Cabinet Size(mm) | 500X500X84.5 | 500X500X84.5 | 500X500X84.5 |
| Cabinet Resolution | 256X256 | 216X216 | 192X192 |
| Module Quantity | 2X2 | 2X2 | 2X2 |
| Cabinet Weight(kg) | 8 | 8 | 8 |
| Maintenance | Front/Rear | Front/Rear | Front/Rear |
| Cabinet Materials | Diecasing Aluminum | Diecasing Aluminum | Diecasing Aluminum |
| Brightness(Nits) | ≥1500 | ≥1500 | ≥1500 |
| Color Temperature(K) | 1000-18500 | 1000-18500 | 1000-18500 |
| Viewing Angle(H/V) | 160°/160° | 160°/160° | 160°/160° |
| Brightness Uniformity | 2-50m | 3-50m | 3-50m |
| Contrast | 10000 : 1 | 10000 : 1 | 10000 : 1 |
| Frame Rate | 60/120 | 60/120 | 60/120 |
| Drive Mode | 1/8 Scan | 1/25 Scan | 1/8 Scan |
| Gray Scale | 16bit | 16bit | 16bit |
| Refresh Rate(Hz) | 7680 | 7680 | 7680 |
| Max Power Consum(W/㎡) | 920 | 920 | 920 |
| Aver Power Consum(W/㎡) | 200-300 | 200-300 | 200-300 |
| Waterproof Level | IP31 | IP31 | IP31 |
| Input Voltate | AC90-264V,47-63Hz | ||
| Working Temp(℃/RH) | -20~60℃/10%~85% | ||
| Storage Temp(℃/RH) | -20~60℃/10%~85% | ||
| Applicable standard | CCC/CE/RoHS/FCC/CB/TUV/IEC |
